Affordable Large Capacity 120m³ Concrete Batching Plant - Ready Mix Concrete Plant Price
Introducing the Large Capacity 120m3 Ready Mixed Concrete Batching Plant by CHANGSHA AICHEN INDUSTRY AND TRADE CO., LTD., a leading manufacturer and supplier in the concrete industry. Designed to meet the demands of modern construction, our concrete batching plants are the ideal solution for producing high-quality ready-mixed concrete at competitive prices.
Our concrete batching plant offers a versatile solution tailored for various applications, whether you operate a construction company, a concrete supplier, or a manufacturing unit. The robust design ensures reliable operation, while the large capacity allows you to meet the high demands of your projects efficiently.
Key features of our batching plant include:
1. Aggregate Storage Bin: Our batching machines feature an aggregate storage system that allows for cumulative and single measurement batching, ensuring precise proportions of sand and stone for optimal concrete quality.
2. Aggregate Pre-storage Bin: This innovative design allows for immediate mixing of aggregate materials, significantly boosting production efficiency and reducing waiting times.
3. Powder Silo: Designed for storing essential materials such as cement, fly ash, and mineral powder, our powder silo facilitates a smooth and continuous mixing process.
4. Additive Storage Bin: The additive storage bin is specifically designed to hold various additive materials, enhancing the properties of concrete for tailored applications.
5. Conveying Systems: Equipped with flat belt and inclined conveyors, our batching plant ensures seamless transportation of aggregate material post-batching and weighing, enhancing operational efficiency.
6. Measurement Systems: Our plants utilize advanced single and cumulative measurement technologies, featuring high-precision tension sensors for accurate weighing of all materials.
7. Water and Additive Metering: The water metering bucket and additive metering hopper facilitate precise control of water and additive ratios, crucial for high-quality concrete production.
CHANGSHA AICHEN stands out as a trusted concrete batching plant manufacturer, offering not only high-standard equipment but also exceptional customer service. Our products are designed with durability and efficiency in mind, ensuring long-term performance in various working conditions.
Whether you need a stationary concrete batching plant or a mini mobile concrete batching plant, our comprehensive range of solutions caters to diverse needs. We also offer the HZS60 concrete batching plant, known for its reliability and compact design, perfect for smaller projects without compromising on quality.
Choose CHANGSHA AICHEN as your concrete batching plant supplier and experience unparalleled quality and service. With our competitive prices and innovative solutions, you can elevate your construction projects to new heights. Contact us today to learn more about our large capacity concrete batching plants and receive a customized quote!
Control Room, Electric Control Cabinet, Operation Console
Shipping
Our Customer
Introducing the Affordable Large Capacity 120m³ Concrete Batching Plant by CHANGSHA AICHEN, a robust solution tailored for businesses looking to maximize production without compromising on quality. This state-of-the-art ready mix concrete plant is designed to deliver excellent performance and reliability, ensuring that your operations run smoothly and efficiently. With a significant focus on enhancing productivity, this batching plant integrates sophisticated technology with user-friendly features, making it an ideal choice for both large-scale and smaller concrete projects. When it comes to ready mix concrete plant prices, AICHEN offers remarkable value for high-quality systems that meet your production demands. Our concrete batching plant features a comprehensive Aggregate Storage Bin that is critical for managing various materials. The aggregate batching machine offers both cumulative and single measurement batching options, allowing for the precise regulation of sand and stone needed for your mixes. The Aggregate Pre-storage Bin is designed to keep aggregate materials readily available for quick mixing, significantly improving production efficiency. With the addition of a Powder Silo that accommodates cement, fly ash, and mineral powder, you can rest assured that all necessary components are easily managed within a single, integrated system. This arrangement streamlines your workflow and contributes to more competitive ready mix concrete plant prices for your projects. To further enhance your operations, we have equipped the batching plant with a flat belt conveyor for efficient material transmission, alongside a lifting hopper for seamless loading of aggregates into the mixing system. Additionally, the inclined belt conveyor ensures that aggregates are smoothly transferred into the mixing chamber, while the conveying system is designed to facilitate the movement of powder materials from storage to mixing units. Our single measurement and cumulative measurement systems offer precise control over ingredient proportions, thanks to advanced weighing technology via tension sensors. Every aspect of the CHANGSHA AICHEN concrete batching plant is optimized to deliver the best results at an affordable ready mix concrete plant price, making it an essential investment for contractors and builders alike.
-
Fully enclosed conveyor belt conveyor, effectively preventing dust leakage 25、35、 50、60,、75、90,、120、180、240、270、 Cubic Meters/Hour
Product Description
Aggregate Storage Bin
Aggregate batching machine includes cumulative / single measurement batching way which mainly for sand , stone
Aggregate Pre-storage Bin
Aggregate storage bin could have aggregate material ready for once mixing , in order to improve the production efficiency
Powder Silo
Powder silo mostly for cement , flyash and mineral powder material
Additive Storage Bin
Additive storage bin is use for additive material storage water common comes from water well or lake
Flat Belt Conveyor
Use for aggregate material transmission after batching and weighing
Lifting Hopper
Use for loading the aggregate material into mixing system
Inclined Belt Conveyor
Use for loading the aggregate material into mixing system
Conveying System
Use for transmission of powder material from storage into mixing system
Single Measurement
There is a measuring hopper below each type of aggregate bin, and three tension sensors are hung through suspension bolts for weighing
Cumulative Measurement
There is only one measuring hopper under the aggregate bin, and four tension sensors are hung through suspension bolts for weighing
Single Measurement
The powder is transported to the powder measuring hopper through a screw conveyor and weighed by sensors on the measuring hopper
Water Metering Bucket
Directly transport water to the water metering hopper through a submersible pump
Additive Metering Hopper
Transport water to the metering hopper through sewage pump
Control Room, Electric Control Cabinet, Operation Console
With the function of ratio storage, automatic compensation of drop, compensation of sand and stone moisture content (sand and stone moisture content tester needs to be ordered separately), it can accurately and conveniently input, adjust and modify the set value and formula number of each material
Product Details
Specification
Model | HZS25 | HZS35 | HZS50 | HZS60 | HZS75 | HZS90 | HZS120 | HZS150 | HZS180 |
Discharging Capacity (L) | 500 | 750 | 1000 | 1000 | 1500 | 1500 | 2000 | 2500 | 3000 |
Charging Capacity(L) | 800 | 1200 | 1600 | 1600 | 2400 | 2400 | 3200 | 4000 | 4800 |
Maximum Productivity(m³/h) | 25 | 35 | 50 | 60 | 75 | 90 | 120 | 150 | 180 |
Charging Model | Skip Hopper | Skip Hopper | Skip Hopper | belt conveyor | Skip Hopper | belt conveyor | belt conveyor | belt conveyor | belt conveyor |
Standard Discharging Height(m) | 1.5~3.8 | 2~4.2 | 4.2 | 4.2 | 4.2 | 4.2 | 3.8~4.5 | 4.5 | 4.5 |
Number of Species of Aggregate | 2~3 | 2~3 | 3~4 | 3~4 | 3~4 | 4 | 4 | 4 | 4 |
Maximum Aggregate Size(mm) | ≤60mm | ≤80mm | ≤80mm | ≤80mm | ≤80mm | ≤80mm | ≤120mm | ≤150mm | ≤180mm |
Cement/Powder Silo Capacity(set) | 1×100T | 2×100T | 3×100T | 3×100T | 3×100T | 3×100T | 4×100T or 200T | 4×200T | 4×200T |
Mixing Cycle Time(s) | 72 | 60 | 60 | 60 | 60 | 60 | 60 | 30 | 30 |
Total Installed Capacity(kw) | 60 | 65.5 | 85 | 100 | 145 | 164 | 210 | 230 | 288 |
Shipping
Our Customer
FAQ
Question 1: Are you factory or a trading company?
Answer: We are a factory dedicated in concrete batching plant over 15 years, all the supporting equipment are available, including but not limited to batching machine, Stabilized soil batching plant, cement silo, concrete mixers, screw conveyor, etc.
Answer: We are a factory dedicated in concrete batching plant over 15 years, all the supporting equipment are available, including but not limited to batching machine, Stabilized soil batching plant, cement silo, concrete mixers, screw conveyor, etc.
Answer: Just tell us the capacity (m3/day)of concrete you want to produce concrete per day or per month.
Question 3: What's your advantage?
Answer: Rich production experience, Excellent design team, Strict quality audit department, Strong after-sales installation team
Answer: Rich production experience, Excellent design team, Strict quality audit department, Strong after-sales installation team
Question 4: Do you supply training and after-sale service?
Answer: Yes, we will supply installation and training on site and also we have a professional service team that can solve all the problems ASAP.
Answer: Yes, we will supply installation and training on site and also we have a professional service team that can solve all the problems ASAP.
Question 5: What about the payment terms and incoterms?
Answer: We can accept T/T and L/C, 30% deposit, 70% balance before shipment.
EXW, FOB, CIF, CFR these are the common incoterms we operating.
Question 6: What about the delivery time?
Answer: Normally, the stock items can be send out in 1~2 days after receive the payment.
For customized product, the production time need about 7~15 working days.
Question 7: What about the warranty?
Answer: All of our machines can provide 12-months warranty.
